| Warranty: | 12 Month | Customized Support: | OEM, ODM |
|---|---|---|---|
| Product Name: | Pressure Transmitter | Port: | Tianjin |
|
Specifications:
|
|
|
|
Measurement Range
|
-0.1．．．0~0.01．．．~100MPa
|
|
|
Proof Pressure
|
≤1.5X rated pressure or 110MPa which ever is less
|
|
|
Pressure Type
|
Gauge, absolute ,sealed gauge
|
|
|
Accuracy
|
±0.25%(Typical) ±0.5%(Max.)
|
|
|
Long Term Stability
|
±0.1%F.S/year( Typical ) ±0.2%F.S/year( Max.)
|
|
|
Temperature Error-Zero
|
±0.03%F.S/℃(≤100KPa) ±0.02%F.S/℃(＞100KPa)
|
|
|
Temperature Error-Span
|
±0.03%F.S/℃(≤100KPa) ±0.02%F.S/℃(＞100KPa)
|
|
|
Operating Temperature Range
|
-20℃~80℃
|
|
|
Storage Temperature Range
|
-40℃~120℃
|
|
|
Power Supply
|
15~30V DC
|
|
|
Output Signal
|
4～20mA 0～10/20mA 0/1～5VDC
|
|
|
Pressure Port
|
M20×1.5 G1/2 or customized
|
|
|
Main Part Material
|
Stainless Steel
|
|
|
Diaphragm Material
|
316L
|
|
|
O-ring
|
Fluororubber
|
|
|
Cable
|
Polyethylene
|
|
|
Insulation Resistance
|
100MΩ 100V DC
|
|
|
IP Grade
|
IP65
|
|
