Warranty: | 12 Month | Customized Support: | OEM, ODM |
---|---|---|---|
Product Name: | Differential Pressure Transmitter | Theory: | High-Precision Micro Pressure Core |
Output Signal: | 4~20mA, 0~10V DC, 0~5V DC | Pressure Range: | ±10000pa |
Application: | Industrial Automation | Power Supply: | 16~30V DC |
Operating Temperature: | -10℃~60℃ | IP Grade: | IP65 |
Model | AF110 |
Medium | Air, neutral gas |
Pressure Range | -100Pa~1000Pa~10KPa |
Simulate Range | 0~10000Pa |
Accuracy | 0.5%FS, 1%FS |
Power Supply | 16~30V DC |
Output Signal | 4~20mA, 0~10V DC, 0~5V DC |
Operating Temperature | -10℃~60℃ |
Compensate Range | -10℃~70℃ |
Pressure Connection | Max diameter: Ø 8 mm |
Display | LCD display, 50x22.5mm |
IP Grade | IP65 |
