Warranty: | 12 Month | Customized Support: | OEM, ODM, OBM |
---|---|---|---|
Temperature Output: | 4-20mA, 0-10V | Humidity Output: | 4-20mA (load≤500 Ohm), 0-10V |
Working Voltage: | 12-35V DC | Power Consumption: | ≤1 VA (typical Value) |
Allowable Maximum Air Flow Speed:: | 16 M / S | Temperature Transmitting Range:: | 0 ~ 50 ℃ |
Working Temperature: | -40~80℃ | Working Humidity: | 0-99% RH |
Storage Temperature:: | - 40 ~ 80 ℃ | Storage Humidity: | 20~60% RH |
Specification | ||||
Product name | Temperature and humidity transmitter | |||
Model | 3005-TH-120 | |||
Allowable maximum air velocity | 16m/s | |||
Electrial connections | 1x2.5 mm2 / 2x1.5 mm2 (Terminal capacity),M12x1.5mm (Waterproof connector) | |||
Output signal | Temperature | 4-20mA, 0-10V | ||
Humidity | 4-20mA, 0-10V (load≤500 ohm) | |||
Voltage | Working voltage | 12-35V DC | ||
Power consumption | ≤1V A (typical) | |||
Temperature | Transmission range | 0-50℃ (factory default) or customized | ||
Accuracy | ±0.3℃ (Full-scale average) | |||
Long-term stability | <0.04℃/year | |||
Relative humidity | Range | 0-100% RH | ||
Accuracy | ±3% RH (typical, at 25℃) | |||
Long-term stability | <0.5% RH/year | |||
Working environment | Temperature | -40~80℃ | ||
Humidity | 0-99% RH (no condensation) | |||
Storage environment | Temperature | -40~80℃ | ||
Humidity | 20-60% RH |
