| Place of Origin: | Beijing, China |
|---|---|
| Brand Name: | IVANPER |
| Model Number: | AF410 |
| Minimum Order Quantity: | 10 units |
| Price: | $95.00/units 10-29 units |
| Packaging Details: | Carton / wooden box |
| Supply Ability: | 1000 Piece/Pieces per Week |
| Warranty: | 1 Year | Type: | Industrial |
|---|---|---|---|
| Customized Support: | OEM, ODM | Product Name: | Air Speed Sensor/transmitter |
| Usage: | Speed Sensor | Theory: | Inductance Sensor |
| Power Supply: | 12~30VDC | Measure Range: | 0-5m/s, 0-10m/s, 0-20m/s, 0-30m/s Or Customized |
| Output Signal: | RS485 / 4-20ma / 0-5v / 0-10v | Operating Temperature: | -20~80℃ |
| Resolution: | 0.01m/s | Humidity: | 5%-95% |
| Probe Diameter: | 12mm Or Customized | Port: | Tianjin |
Specifications | |
Power Supply | 24V DC/AC |
Measure Range | 0-1m/s 0-2m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s |
Output | 0-10V 4-20mA Rs485{modbus-RTU} |
Measure Accuracy | ±{0.2m/s +3%of MV} |
Consumption | 2.5W |
Protection Rating | IP65 |
Response Latency | 0.2 s |
Resolution | 0.01m/s |
Sensing Elements | Thermal film sensor |
Working Environment | Temperature: -40-80ºC Humidity:5%-95% |
Probe Length | Installation of flange :150mm / Customization |
Material of Probe | ABS Engineering plastic |
Rod diameter | 12mm, rod length: 220mm (customized), can be made of aluminum alloy |
