Warranty: | 12 Month | Type: | Industrial |
---|---|---|---|
Customized Support: | OEM, ODM, OBM | Product Name: | Anemometers Wind Speed Sensor |
Power Supply: | 24VDC | Measuring Range: | 0-1m/s, 0-2m/s, 0-10m/s, 0-15m/s, 0-20m/s, 0-30m/s |
Output: | 0-10V 4-20mA RS485 Modbus | Accuracy: | ±(0.2m/s+3% Of MV) |
Consumption: | 2.5W | IP Class: | IP65 |
Response Latency: | 0.2s | Port: | Tianjin |
Product name | Wind speed sensor |
Model | AF410 |
Power supply | 24V DC/AC |
Measure range | 0-1m/s 0-2m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s (Customized) |
Output | 0-10V 4-20mA Rs485{modbus-RTU} |
Accuracy | ±{0.2m/s +3%of MV} |
Consumption | 2.5W |
Protection class | IP65 |
Response latency | 0.2s |
Resolution | 0.01m/s |
Sensing elements | Thermal film sensor |
Working environment | Temperature: -40~80℃, Humidity: 5%~95% |
Probe length | Installation of flange :150mm / Customization |
Material of probe | ABS engineering plastic |
Probe diameter | 14mm, probe length: 220mm (customized), can be made of aluminum alloy |
