Warranty: | 1 Year | Type: | Industrial |
---|---|---|---|
Customized Support: | OEM, ODM, OBM | Product Name: | Wind Speed Sensor |
Measuring Range: | 0-1m/s, 0-2m/s, 0-10m/s, 0-15m/s, 0-20m/s, 0-30m/s | Accuracy: | ±(0.2m/s+3% Of MV) |
Ingress Protection: | IP65 | Power Supply: | 12~30VDC |
Output: | RS485/ 4-20mA/ 0~10V | Consumption: | 2.5W |
Response Latency: | 0.2s | Port: | TIANJIN |
Specifications | |
Power Supply | 12V DC/AC 24V DC/AC |
Measure Range | 0-1m/s 0-2m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s |
Output | 0-10V 4-20mA Rs485{modbus-RTU} |
Measure Accuracy | ±{0.2m/s +3%of MV} |
Consumption | 2.5W |
Protection Rating | IP65 |
Response Latency | 0.2 s |
Resolution | 0.01m/s |
Sensing Elements | Thermal film sensor |
Working Environment | Temperature: -40-80ºC Humidity:5%-95% |
Probe Length | Installation of flange :150mm / Customization |
Material of Probe | ABS Engineering plastic |
Rod diameter | 12mm, rod length: 220mm (customized), can be made of aluminum alloy |
