| Place of Origin: | China |
|---|---|
| Brand Name: | IVAN |
| Model Number: | AF6900 |
| Price: | $6,250.00/units >=1 units |
| Packaging Details: | Wooden packing |
| Supply Ability: | 50 Unit/Units per Month |
| Warranty: | 12 Month | Port: | Tianjin |
|---|
Model | AF 6900 | ||||||
Air Flow | Ranges | Flow Grid: 21 to 377 CFM (36 to 640 m3/h) | |||||
Nozzle: 2 to 21 CFM (4 to 36 m3/h) | |||||||
Accuracy | 2.5 % of Reading±0.1 m3/h | ||||||
Resolution | 0.01 m3/h | ||||||
Pressure | Ranges | ± 10 in.wg (± 2500 Pa) | |||||
Accuracy | 1% of Reading ± 1 Pa | ||||||
Resolution | 0.1 Pa | ||||||
Temperature | Ranges | 32 to 140 °F (0 to 60 °C) | |||||
Accuracy | ±0.5 °C | ||||||
Resolution | 0.1 °C | ||||||
Absolute Pressure | Ranges | 20.6 to 38.3 in.Hg (70 to 130kPa) | |||||
Accuracy | 2% of Reading | ||||||
Resolution | 0.1kPa | ||||||
Power Source | AF 6900-0E | 110-120V, 1 Phase, 50/60Hz,16A | |||||
AF 6900-1E | 220-240V, 1 Phase, 50/60Hz,10A | ||||||
Weight | Approx.75kg | ||||||
Dimensions | W21 x D20 x H47 inches (54 x 50 x 120 mm) | ||||||
Data logging | Up to 1000 measurements | ||||||
