Warranty: | 12 Month | Type: | Industrial |
---|---|---|---|
Customized Support: | OEM, ODM | Product Name: | Speed Meter Velocimetry |
Power Supply: | 24VDC | Measuring Range: | 0-30m/s |
Output: | 0-10V/4-20mA/Rs485 | Application: | HVAC Test |
Port: | TIANJIN |
Specifications | |
Power Supply | 12V DC/AC 24V DC/AC 5VDC/AC {Customization} |
Measure Range | 0-1m/s 0-2m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s |
Output | 0-5V 0-10V 0-20mA 4-20mA Rs485{modbus-RTU} |
Measure Accuracy | ±{0.2m/s +3%of MV} |
Consumption | 2.5W |
Protection Rating | IP65 |
Response Latency | 0.2 s |
Resolution | 0.01m/s |
Sensing Elements | Thermal film sensor |
Working Environment | Temperature: -40-80ºC Humidity:5%-95% |
Probe Length | Installation of flange :150mm / Customization |
Material of Probe | ABS Engineering plastic |
Rod diameter | 12mm, rod length: 220mm (customized), can be made of aluminum alloy |
