| Place of Origin: | Beijing, China |
|---|---|
| Brand Name: | IVANPER |
| Model Number: | AF410A2 |
| Minimum Order Quantity: | 10 units |
| Price: | $95.00/units 10-99 units |
| Packaging Details: | carton |
| Supply Ability: | 1000 Piece/Pieces per Week |
| Warranty: | 1 Year | Type: | Digital Wind Speed Meter |
|---|---|---|---|
| Customized Support: | OEM, ODM | Product Name: | Wind Speed Sensor |
| Power Supply: | 12V DC/AC, 24V DC/AC | Measuring Range: | 0-5m/s, 0-10m/s, 0-20m/s, 0-30m/s |
| Output: | 0-10V, 4-20mA, RS485 | Accuracy: | ±{0.2m/s +3%of MV} |
| Consumption: | 2.5W | Protection Class: | IP65 |
| Response Latency: | 0.2s | Resolution: | 0.01m/s |
| Sensing Elements: | Thermal Film Sensor | Port: | Tianjin |
Specifications | |
Power Supply | 12V DC/AC 24V DC/AC {Customization} |
Measure Range | 0-1m/s 0-2m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s 0-40m/s 0-50m/s 0-60m/s 0-80m/s |
Output | 0-5V 0-10V 0-20mA 4-20mA Rs485{modbus-RTU} |
Measure Accuracy | ±{0.2m/s +3%of MV} |
Consumption | 2.5W |
Protection Rating | IP65 |
Response Latency | 0.2 s |
Resolution | 0.01m/s |
Sensing Elements | Thermal film sensor |
Working Environment | Temperature: -20-80ºC Humidity:5%-95% |
Probe Length | Installation of flange :150mm / Customization |
Material of Probe | ABS Engineering plastic |
Rod diameter | 14mm, rod length: 220mm (customized), can be made of aluminum alloy |
