| Place of Origin: | Beijing, China |
|---|---|
| Brand Name: | Ivan |
| Model Number: | AF410A2 |
| Minimum Order Quantity: | 10 units |
| Price: | $110.00/units 10-99 units |
| Packaging Details: | carton |
| Supply Ability: | 1000 Piece/Pieces per Week |
| Type: | Digital Wind Speed Meter | Output: | RS485 |
|---|---|---|---|
| Product Name: | Air Velocity Sensor | Accuracy: | ±{0.2m/s +3%of MV} |
| Color: | Gray | Measuring Range: | 0-70M/Scustomizable |
| Resolution: | 0.01m/s | Display: | LED Display |
| Operate Temperature: | -20-80 | Application: | Air |
| Material: | ABS | Port: | Tianjin |
Specifications | ||
Power Supply | 12V DC/AC 24V DC/AC {Customization} | |
Measure Range | 0-1m/s 0-2m/s 0-10m/s 0-15m/s 0-20m/s 0-30m/s 0-40m/s 0-50m/s 0-60m/s 0-80m/s | 0-20m/s 0-80m/s |
Output | 0-5V 0-10V 0-20mA 4-20mA Rs485{modbus-RTU} | |
Measure Accuracy | ±{0.2m/s +3%of MV} | |
Consumption | 2.5W | |
Protection Rating | IP65 | |
Response Latency | 0.2 s | |
Resolution | 0.01m/s | |
Sensing Elements | Thermal film sensor | |
Working Environment | Temperature: -20-80ºC Humidity:5%-95% | |
Probe Length | Installation of flange :150mm / Customization | |
Material of Probe | ABS Engineering plastic | |
Rod diameter | 14mm, rod length: 220mm (customized), can be made of aluminum alloy |
